LaTeX interface

Summarizes SPEC.md §7; SPEC.md is authoritative.

Setup

\usepackage{vouch}               % or \usepackage[short,final]{vouch}

vouch.sty is plain LaTeX2e and needs nothing beyond a current kernel. At the end of the preamble it loads hyperref (unless the document already has), xcolor, and, for the tooltip and note modes, pdfcomment. Under final it loads none of them. It \inputs the values file automatically, so no second line is needed.

Macros

Macro	Renders	Notes
\vouch{key} / \vouch[fmt]{key}	the formatted value	Robust; works in text, math, captions, section titles and table cells.
\vouchraw{key}	the raw number, e.g. 0.93214	Expandable, for pgfplots, \pgfmathparse and siunitx input. No tooltip.
\vouchclaim{key}{prose}	the prose	The tooltip shows the verdict. If the claim is false or unknown, a red marker follows unless final.
\vouchtable{key}	\input of vouch-tables/<key>.tex	Body rows only.
\val, \vclaim, \vtable	aliases	Only with package option short, and only if not already defined.

Missing keys render the way \ref handles missing labels:

• Unknown key: \textbf{??\detokenize{key}}, plus a \PackageWarning and an end-of-document summary.
• Pending key: \fbox{\scriptsize pending: key} (or the placeholder text you configure).

Package options

Option	Effect
provenance=link\|tooltip\|note\|off	how a reader gets from a number to where it came from (default link)
tooltip=key\|value\|full	how much tooltip or note text says (default full)
highlight=off\|changed	color values whose change is not yet acknowledged (default changed)
final	camera-ready: no links, tooltips, notes, colors or appendix, and none of hyperref/pdfcomment/xcolor is loaded. Pending or unknown keys and false claims still render their markers and raise a LaTeX error, so a final build cannot silently ship a placeholder or a falsified claim.
short	defines the short aliases above
values=FILE	the generated values file (default vouch-values.tex)

From a number to its provenance, in the PDF

Hover tooltips turned out not to be portable across viewers, so there are four modes:

Mode	What the reader does	Works in
link (default)	clicks a number and lands on its entry in a generated "Value provenance" appendix; the entry links back to every page that cites it	every viewer
tooltip	hovers over a number	Acrobat, Firefox; not Chrome or Edge
note	hovers over or clicks a sticky-note icon beside each number	most desktop viewers; visually busy
off	—	—

examples/viewer-check/viewer-check.tex in the repository compiles a one-page test of all three, so a team can check the viewers it uses.

Link mode. In drafts, every \vouch value, \vouchclaim prose span and generated table cell is a link, colored vouchvalue (a muted blue). At the end of the draft, or where \vouchprovenance is placed, the appendix lists every cited key in order of first citation.

A cited number, linked to its provenance appendix entry.

Each entry shows:

• the key and its rendered value, with "cited on p. 1, 3" (each page number links back)
• the description, the raw value, and the table it belongs to (for table cells)
• for a value recorded by a tracked function: the call, how long the calls took, each call's own result, and the function's definition and call sites
• run, file:line and command
• date, commit, and the run's current state (fresh, STALE – models.py::f changed, …)
• for an unacknowledged change, "CHANGED: was 93.2% (acked 2026-09-10)" in the highlight color

One appendix entry with full call provenance.

Notes on how PDF links work here:

• Page numbers come from the .aux file, so they appear after the second LaTeX run, as with \ref.
• Links can't nest. A claim's prose is one link; values inside it don't make links of their own (they still appear in the appendix).
• hyperref. If the document doesn't load it, vouch loads it with hidelinks. If it does, its settings win for claim prose; vouched numbers keep vouchvalue.

Tooltip mode. Values are wrapped in pdfcomment's \pdftooltip. With tooltip=full:

cifar.resnet.acc = 0.93214 (±0.0041, n=5)
run cifar_resnet · experiments/train.py:88
python experiments/train.py --model resnet50 --seeds 5
2026-09-12 14:03 UTC · git 0fdc530 · state: fresh

Changed-value highlighting

A cited value whose change is pending is rendered in a highlight color (configurable). Skimming the PDF then shows exactly which sentences to re-read. Highlighting is off under final. See Change notification.

The values file

paper/vouch-values.tex is generated, sorted and deterministic. It has no timestamps, so an unchanged build is a byte-identical file:

% vouch-values.tex -- GENERATED by `vouch build`. Do not edit: `vouch check` detects edits.
% 38 values · 3 claims · 1 table · 1 pending
\vouch@set{cifar.resnet.acc}{}{\ensuremath{93.2 \pm 0.4}\%}{93.2 +/- 0.4\%}{<tooltip>}{0}
\vouch@raw{cifar.resnet.acc}{0.93214}
\vouch@claim{cifar.resnet_beats_vit}{1}{<tooltip>}{0}
\vouch@pending{imagenet.convnext.acc}{python experiments/train.py --dataset imagenet --model convnext}
\vouch@table{main}{vouch-tables/main.tex}

Every recorded key is written at its default format, so co-authors on Overleaf can cite any recorded key without a local build; formats the paper overrides are written in addition. The generated file's git diff is a readable record of every number that moved.

How the paper is scanned

• File graph. Starting from each [[paper]] main, it follows \input, \include, \subfile, \import/\subimport.
• Comments are blanked with offsets preserved. Environments listed in lint.skip_envs are skipped.
• Citations found: \vouch[opt]{key}, \vouchraw{key}, \vouchclaim{key}{…}, \vouchtable{key}, the short aliases, and \includegraphics[…]{path}.
• Macro definitions. A citation inside a \newcommand/\renewcommand/\def/\NewDocumentCommand body counts only if that macro is used in the document.
• Sentences. For change notifications, each citation's surrounding sentence is extracted, lightly de-TeXed, and capped at 240 characters.

Source annotations (opt-in: latex.annotate = true)

With annotations on, vouch build (or vouch sync on demand) maintains a managed trailing comment on every source line that cites values:

ResNet-50 reaches \vouch{cifar.resnet.acc} top-1 accuracy, \vouch{cifar.resnet_vs_vit.pts} points  % vouch: cifar.resnet.acc=93.2 ± 0.4%, cifar.resnet_vs_vit.pts=2.0

vouch owns only the % vouch: key=… suffix. Disabling the option and running vouch sync --strip removes every annotation.
